? Wide Input Voltage Range

? 4.5V to 60V

? 4V to 60V (Soft-start is finished)

? Wide Output Voltage Range : 0.8V to VIN

? 0.8V ±1% Reference Accuracy

? Peak Current Mode Control

? Integrated 80mΩ High-Side MOSFET

? Low Quiescent Current : 100μA

? Low Shutdown Current : 2.25μA

? Adjustable Switching : 100kHz to 2.5MHz

? Synchronizable Switching : 300kHz to 2.2MHz

? Power Saving Mode (PSM) at Light Load

? Low Dropout at Light Loads with Integrated Boot

  Recharge FET

? Externally Adjustable Soft-Start by Part Number

  Option

? Power Good Indication by Part Number Option

? Enable Control

? Adjustable UVLO Voltage and Hysteresis

? Built-In UVLO, UVP, OVP, OCP, OTP
