? Insertion power gain: 12.5 dB

? Low noise figure: 0.60 dB

? Low current consumption: 4.7 mA

? Operating frequencies: 2300 - 2690 MHz

? Supply voltage: 1.5 V to 3.3 V

? Digital on/off switch (1V logic high level)

? Ultra small TSNP-6-2 leadless package

  (footprint: 0.7 x 1.1 mm2)

? B7HF Silicon Germanium technology

? RF output internally matched to 50 Ω

? Only 1 external SMD component necessary

? 2kV HBM ESD protection (including AI-pin)

? Pb-free (RoHS compliant) package
