SGM2036-0.9YN5G.pdf? Low Dropout Voltage
? Thermal Overload Protection
? Built-In Fold Back Protection Circuit
? 20μA Low Supply Current
? 10nA Logic-Controlled Shutdown
? 1.6V to 5.5V Input Voltage Range
? Fixed Outputs of 0.8V, 0.9V, 1.0V, 1.05V,
1.1V, 1.2V, 1.3V, 1.35V, 1.5V, 1.8V, 1.85V,
2.1V, 2.2V, 2.3V, 2.5V, 2.6V, 2.7V, 2.8V, 2.85V,
2.9V, 3.0V, 3.1V, 3.3V, 3.6V, 4.2V, 4.4V and 5.0V
? Adjustable Output from 0.8V to 5.0V
? Short Auto-Discharge Function
? 300mA Output Current
? High Output Voltage Accuracy
? Short Start-Up Time
? -40℃ to +85℃ Operating Temperature Range
? Available in Green UTDFN-1×1-4L,
SOT-23-5 and SC70-5 Packages
? 2% Accuracy
? Low IQ: 35 mA
? Fixed-Output Voltage Combinations
Possible from 0.7 V to 1.15 V(1)
? High PSRR: 68 dB at 1 kHz
? Stable with Effective Capacitance of 0.1 mF(2)
? Thermal Shutdown and Overcurrent Protection
? Packages: SOT23-5, 1,5-mm × 1,5-mm SON-6
? For output voltage of 1.2 V and higher, see the
TLV702 family of devices.
? See the Input and Output Capacitor Requirements
in the Application Information section.
