SGM2208.pdf? Power Input Voltage Range (Relative to OUT): 0V to 24V
? Bias Supply Voltage Range (Relative to OUT): 2.7V to 25V
? Single Resistor Programs Output Voltage
? SET Pin Current: 50μA (TYP)
? Output Adjustable to 0V
? Low Output Noise: 32μVRMS (10Hz to 100kHz)
? Low Dropout Voltage: 155mV (TYP) at 3A
? Current Limit with Foldback
? Over-Temperature Protection
? Outputs May be Paralleled for Higher Current and Heat Spreading
? -40℃ to +125℃ Operating Temperature Range
? Output Current: 3A
? Single Resistor Programs Output Voltage
? 50μA Set Pin Current: 1% Initial Accuracy
? Output Adjustable to 0V
? Low Output Noise: 40μVRMS (10Hz to 100kHz)
? Wide Input Voltage Range: 1.2V to 23V
(DD-Pak and TO-220 Packages)
? Low Dropout Voltage: 310mV
? <1mV Load Regulation
? <0.001%/V Line Regulation
? Minimum Load Current: 1mA
? Stable with Minimum 10μF Ceramic Capacitor
