? Single H-Bridge Current-Control Motor Driver

? 8.2-V to 45-V Operating Supply Voltage Range

? Five-Bit Winding Current Control Allows Up to

  32 Current Levels

? Low MOSFET RDS(on) Typical 0.2 ? (HS + LS)

? 5-A Maximum Drive Current at 24 V, 25°C

? Built-In 3.3-V Reference Output

? Industry-Standard PWM Control Interface

? Thermally Enhanced Surface Mount Package

? Protection Features:

  Overcurrent Protection (OCP)

  Thermal Shutdown (TSD)

  VM Undervoltage Lockout (UVLO)

  Fault Condition Indication Pin (nFAULT)
