? Available as an integrated-inductor power module:

  TPSM82821 and TPSM82822

? DCS-Control? topology

? 1% feedback or output voltage accuracy (full

  temperature range)

? Up to 97% efficiency

? 26-mΩ and 25-mΩ internal power MOSFETs

? 2.4-V to 5.5-V input voltage range

? 4-μA operating quiescent current

? 2.2-MHz switching frequency

? Adjustable output voltage from 0.6 V to 4 V

? Power save mode for light load efficiency

? 100% duty cycle for lowest dropout

? Active output discharge

? Power good output

? Thermal shutdown protection

? Hiccup short-circuit protection

? A forced-PWM version for CCM operation

? Create a custom design using the TPS6282x with

  the WEBENCH? Power Designer
