? AEC-Q100 qualified for automotive applications

? Temperature grade 1: –40°C to +150°C, TJ

? Functional Safety-Capable

? Documentation available to aid

  functional safety system design

? Optimized for ultra low EMI requirements

? Hotrod? package and parallel input

  path minimize switch node ringing

? Spread spectrum reduces peak emissions

? Adjustable SW node rise time

? Designed for automotive applications

? Supports 42-V automotive load dump

? ±1% total output regulation accuracy

? VOUT adjustable from 1 V to 95% of VIN

? 0.4-V dropout with 4-A load (typical)

? High efficiency power conversion at all loads

? 7-?A no load current at 13.5 VIN, 3.3 VOUT

? 83% PFM efficiency at 1-mA, 13.5 VIN, 5 VOUT

? External bias option for improved efficiency

? Suitable for scalable power supplies

? Pin compatible with:

? LM61440-Q1 (36 V, 4 A, adjustable fSW)

? LM62440-Q1 (36 V, 4 A, fixed fSW)

? LMQ61460-Q1 (36 V, 6 A, internal caps)
