? Ultra-Low Supply Current: < 1μA (TYP)

? Precision Supply-Voltage Monitor

  4.63V for SGM706B-L

  4.38V for SGM706B-M

  4.0V for SGM706B-J

  3.08V for SGM706B-T

  2.93V for SGM706B-S

  2.63V for SGM706B-R

? Guaranteed nRESET Valid at V_CC = 1V

? Reset Pulse Width: 200ms (TYP)

? Debounced TTL/CMOS-Compatible

? Manual Reset Input

? Watchdog Timer with 1.6s (TYP) Timeout

? 1.25V Threshold Detector for

  Power-Fail or Low-Battery Warning

? -40℃ to +125℃ Operating Temperature Range

? Available in Green UTDFN-1.5×1.5-8L,

  SOIC-8 and MSOP-8 Packages
